Attic Draftstop Access Door Type R302

24 x 60 36 x 48.

Attic draftstop access door type r302. Babcock davis warrants all access doors to be free from manufacturing defects in materials factory finishes and workmanship for a period of one 1 year from the date of shipment. The only place i can see where attic draftstops are referenced in the crc is at section r302 3 for two family dwellings. The drd access door is not insulated. S stainless steel type 304.

718 4 2 groups r 1 and r 2 draftstopping shall be provided in attics mansards overhangs or other concealed roof spaces of group r 2 buildings with three or more dwelling units and in all group r 1 buildings. 24 x 48 36 x 36. It comes with a 1 flange for an easy flush installation on any type of surface material. As per ul standards once the installation is complete and the provided springs installed this door will be self closing and self locking.

Openings in the partitions shall be protected by self closing doors with automatic latches constructed as required for the partitions. Under the 2010 crc is attic draftstopping required under cbc 717 4 sfr attic areas 3000 sf would require it. The 2010 crc r302 12 provides requirements for draftstops at floor ceiling assemblies. R302 12 1 materials draftstopping materials shall be not less than 1 2 inch 12 7 mm gypsum board 3 8 inch 9 5 mm wood structural panels or other approved materials adequately supported.

But not under crc. It comes with a 1 flange for an easy flush installation on any type of surface material. Additional sizes available call for more information. This self closing and self latching access door allows for access from both sides of the door.

Floor framing is constructed of truss type open web or perforated members. Rough opening is door size 1 4 inch minimum.
