Auxiliary gutter fill. 6 auxiliary gutters intended for outdoor use shall be of ap proved rain tight construction. A similar change occurred in article 366 for auxiliary gutters. Now when determining gutter or wireway fill the sum of the cross sectional areas of all contained conductors and cables at any cross section shall not exceed 20 percent of the interior cross sectional area of the wireway. Cable size size of conductors table 2 allowable cable area in2 1.

Electrical safety sizing a gutter for the proper fit is relatively easy. The conductor fill requirements for a conduit or an outlet box are calculated in the field on a regular basis. How to calculate auxiliary gutter fill 366 22 a b categories. Where subject to severe physical damage.

Product comes in 4 ft. I get a lot of calls to make sure that the gutter that they are using is up to code. Splices and taps shall not fill the wireway to more than 75 percent of its area at the point of a splice or tap. Enter or leave the gutter or where the direction of the gutter is de flected greater than 30 degrees dimensions corresponding to section e 373 06 shall apply.

It also includes a custom fill selector so any percent fill can be selected for those jobs where the specs specify more stringent fill than the nec requires. However field people seldom determine the conductor fill requirements for a surface metal or nonmetallic raceway article 352 a metal or nonmetallic wireway article 362 or the wire space for a cabinet or cutout box article 373. Where subject to severe corrosive environments. Thirteen types of raceways can be selected.

Table 1 wireway size cross section in2 max. The raceway fill calculator finds the minimum raceway and wireway and auxiliary gutter sizes.
